Carriages - There are actually 4 sizes of hook type tine carriages rated by the tine carriage hoisting capability. Hook type tine carriages have been the same.
Class I carriages are rated for cargo as much as 2000 lbs. The carriage bar spacing utilized for Class I is thirteen inches. Class II carriages are rated for loads as much as 5,550 lbs. Their carriage bar spacing is sixteen inches. Class III carriages are rated for loads as much as 10,000 lbs. The carriage bar spacing for this class is twenty inches. Class IV carriages are rated for loads up to 15,500 lbs. The carriage bar spacing for this capacity is 25 inches.
The carriages for pin type blades may be different depending on the manufacturer. Pin mounted forks can vary by the amount of offset between the tine eye and the tine. Carriage capacity would be determined by the carriage pin size and by the fork size.
